The design and development process of a printed circuit board (PCB) is divided into several steps. Each step is essential for creating a circuit that can perform necessary operations in a short amount of time.  First, you must select the materials and physical structure (layering and stacking) of your PCB. After that, it is necessary to position the components according to their distribution among the layers and route the traces.  We will explain that last point further and offer a few tips that will help you simplify routing while avoiding some common pitfalls. If you follow these tips, routing can be one of the most delicate and rewarding stages of PCB design. For...
